The explosion of electric-assist bike technology has radically changed the world of cycling. Not only are avid mountain bikers exploring new terrain and taking on bigger obstacles, but the capabilities of the entire electric assist system have increased dramatically. As a result, bikes and their components must meet entirely new performance and safety requirements. People are riding farther, faster and carrying more gear over more varied terrain than ever before, and they need a proven, high-performance suspension system that can meet this new range of needs.
Leveraging Fox ‘s extensive experience in building the world’s highest-performing off-road suspension systems, the new AWL fork is based on the popular Fox 34 frame. Featuring lightweight, yet rigid 34mm forks and a precision-molded magnesium bottom bracket, the AWL tracks precisely without any unwanted flex and ensures long-term optimal performance, no matter what weather or terrain you’re facing. Performance and adjustability are paramount with our infinitely adjustable EVOL air spring and proven Rail shock. Fork rebound and compression adjustments are easily accessible without tools, while the Rail sealed shock system offers exceptional performance, rock-solid reliability and easy maintenance.
The AWL’s sturdy frame is available in 27.5″ and 29″ wheel sizes and has been rigorously tested to withstand a total weight of 169 kg. Mudguard, rack and light mounts are integrated into the fork for optimal compatibility, durability and versatility. Unfavorable conditions, rocks and roots will no longer damage your fenders. The AWL fork is also equipped with a special bracket for a soon-to-be-released next-level safety feature. Designed to handle whatever you throw at it and move smoothly and precisely over any terrain, the AWL can unlock your bike’s electric potential, open up new landscapes and make adventure your everyday life.
Details
- Fork adapted and specially designed for VTTAE
- Max tire width : 29 x 2.80″ (2.6″ with mudguard)
- Size: 29”
- Tapered pivot 1”1/8-1.5
- Axle: Boost 15×110 mm
- Shock absorber: Rail
- Evol air chamber
- Spring: Air
- Offset: 51 mm
- Plungers: 34 mm
- Compatible with discs from 160 to 230 mm (with adapter)
- 3 positions (open / platform / closed)
- Trigger
- Compression
- Steering star.
- QR axis.
- Air volume adjustment wedge.
- 910-20-210 / 34 Float AWL Rail Sweep-Adj 29” | Boost 15x110mm | Deport 51 | Black 2023 100 mm
- 910-21-045 / 34 Float AWL Rail Sweep-Adj 29” | Boost 15x110mm | Deport 51 | Black 2023 140 mm
Float Shock:
The FLOAT air shock developed for the 32, 34 and 40 forks is lighter and reduces the force required to release. It offers excellent sensitivity over small bumps regardless of rider and pressure setting.
Similar to our FLOAT shocks, the new FLOAT system features self-balancing negative and positive chambers. This provides the appropriate pressure for each rider. The progressiveness of the damping curve is adjustable by means of air volume spacers so that mountain bikers can fine-tune the behavior of the air shock
MORE INFORMATION
| Steerer | Tapered 1”1/8-1.5” |
| Front axle | Boost 15 x 110 mm |
| Lock | On the crown |
| Width | 34mm |
| Fork Caliper Mount | Post Mount (PM) |
| Offset (mm) | 51 |
| Size | 100, 140 |
|---|
